Testsysteem HVX-21 High Volltage 2100Vdc/1200Vac 128-TP Merk: CableEye Productcode: 829A+CE CableEye® HVX & HVX-21 Test Systems for Continuity, Resistance, Capacitance, Twisted Pair, and High Voltage Testing Applied Voltage: 2100 Vdc / 1200 Vac Resistance Measurement: Between 0.1 Ω and 5 GΩ Precision Resistance Measurement Options: From 20 mΩ (Advanced Measurement Option), 1 mΩ (4-Wire Kelvin Option) Insulation Resistance Measurement:5 GΩ Insulation Resistance Measurement Current Sensitivity: 0.2 µA Test Points: 128 (Expandable to 1024) Plus 24 Accessory Test Points Sockets: LV Remote Control; Probe (Probe Included) Tests to Industry Standard A620B Guidelines For diagnostic and Pass/Fail Testing Tests for insulation resistance and dielectric breakdown after checking for opens, shorts, miswires, & resistance limits Board sets are not included Details Merk CableEye Productcode 829A+CE Website fabrikant Fabrikantartikelcode HVX-21 Type (BME) HVX-21 Toon alles van dit type Serie Testers Toon alles in deze serie ETIM-klasse Measuring instrument set Toon alles in deze klasse GLN 2220000165174 Herkomstland United States Technische informatie Serie Testers Type HVX-21 ETIM Klasse Meetapparatuurset Bestelinformatie SKU GCE829A00 MPN 829A+CE Bestelbaar Catalogusproduct Levertijd 14 dagen Omverpakking 1 Minimale bestelhoeveelheid 1 Uitgebreide code GCE0 Documenten
